1746-IB8 24V dc 8 Current Sinking DC Input Module.
1746-IB16 24V dc 16 Current Sinking DC Input Module.
1746-IB32 24V dc 32 Current Sinking DC Input Module.
1746-ITB16 24V dc 16 Fast Response DC Sinking Input Module.
1746-IB8 24V dc 8 Current Sinking DC Input Module.
Sinking DC Input Modules
1746-IB16 24V dc 16 Current Sinking DC Input Module.
1746-IB32 24V dc 32 Current Sinking DC Input Module.
1746-ITB16 24V dc 16 Fast Response DC Sinking Input Module.
1746-IC16 48V dc 16 Current Sinking DC Input Module.
1746-IH16 125V dc 16 Current Sinking DC Input Module.
1746-IV8 24V dc 8 Current Sourcing DC Input Module.
-Sourcing DC Input Modules-
1746-IV16 24V dc 16 Current Sourcing DC Input Module.
1746-IV32 24V dc 32 Current Sourcing DC Input Module.
1746-ITV16 24V dc 16 Fast Response DC Sourcing Input Module.
1746-IG16 5V dc 16 Current Sourcing TTL Input Module.
1746-OB6EI 24V dc 6 Electronically Protected Isolated Sourcing DC Output Module.
-Sourcing DC Output Modules-
1746-OB8 24V dc 8 Current Sourcing DC Output Module.
1746-OB16 24V dc 16 Current Sourcing DC Output Module.
1746-OB16E 24V dc 16 Electronically Protected Current Sourcing DC Output Module.
1746-OB32 24V dc 32 Current Sourcing DC Output Module.
1746-OB32E 24V dc 32 Electronically Protected Current Sourcing DC Output Module.
1746-OBP8 24V dc 8 High Current Sourcing DC Output Module.
1746-OBP16 24V dc 16 High Current Sourcing DC Output Module.
1746-OV8 24V dc 8 Current Sinking DC Output Module.
-Sinking DC Output Modules-
1746-0V16 24V dc 16 Current Sinking DC Output Module.
1746-0V32 24V dc 32 Current Sinking DC Output Module.
1746-0VP16 24V dc 16 High Current Sinking DC Output Module.
1746-0G16 5V dc 16 Current Sinking TTL Output Module.
-Analog I/O Module-
1746-NI4 High Resolution (4) Analog Input Module -20…+20 mA (or) -10…+10V dc.
1746-NI8 High Resolution (8) Analog Input Module -20…+20 mA (or) -10…+10V dc.
1746-NI16I✶ High Resolution (16) Analog Input Module -20…+20 mA.
1746-NI16V✶ High Resolution (16) Analog Input Module -10…+10V dc.
1746-NI04I High Resolution (2) Analog Input, (2) Analog Current Output Module -20…+20 mA (or) -10…+10V dc (Inputs)0…20 mA (Outputs).
1746-NIO4V
High Resolution (2) Analog Input, (2) Analog Voltage Output Module 20…+20 mA (or) -10…+10V dc (Inputs)-10…+10V dc Outputs).
1746-FIO4I (2) Fast Analog Input, (2) Analog Current Output Module 0…20 mA (or) 0…10V dc (Inputs)0…20 mA (Outputs)./li>
1746-FIO4V (2) Fast Analog Input, (2) Analog Voltage Output Module 0…20 mA (or) 0…10V dc (Inputs)-10…+10V dc (Outputs).
1746-N04I (4) Analog Current Output Module 0…20 mA.
1746-N04V (4) Analog Voltage Output Module -10…+10V dc.
1746-N08I (8) Analog Current Output Module 0…20 mA.
1746-N08V (8) Analog Voltage Output Module.
Communication Cables
1761-CBL-AC00
SLC 5/03, 5/04, and 5/05 Communication Cable - This 45 cm (17.7 in) cable has two 9-pin DTE connectors and is used to connect the SLC 5/03, 5/04, or 5/05 processor RS-232
channel (channel 0) to port 1 of the 1761-NET-AIC.
1761-CBL-AP00
SLC 5/03, 5/04, and 5/05 Communication Cable - This 45 cm (17.7 in) cable has a 9-pin DTE and an 8-pin mini DIN connector and is used to connect the SLC 5/03, 5/04, or 5/05
processor RS-232 channel (channel 0) to port 2 of the 1761-NET-AIC.
1761-CBL-PM02
SLC 5/03, 5/04, and 5/05 Communication Cable - This 2 m (6.5 ft) cable has a 9-pin DTE and an 8-pin mini DIN connector and is used to connect the SLC 5/03, 5/04, or SLC 5/05
processor RS-232 channel (channel 0) to port 2 of the 1761-NET-AIC.
1761-CBL-AS03
RJ45 to 6-Pin Phoenix Connector Communication Cable - This 3 m (9.8 ft) cable is used to connect the SLC 5/01, SLC 5/02, and SLC 5/03 processor RJ45 port to port 3 of the 1761-
NET-AIC.
1761-CBLAS09
RJ45 to 6-Pin Phoenix Connector Communication Cable - This 9.5 m (31.2 ft) cable is used to connect the SLC 5/01, SLC 5/02, and SLC 5/03 processor RJ45 port to port 3 of the
1761-NET-AIC.
1747-CP3
SLC 5/03, 5/04, and 5/05 RS-232 Programmer Cable - This 3 m (10 ft) cable has two 9-pin DTE connectors and is used to connect the SLC processor RS-232 channel (channel 0) to
a personal computer serial port.
1747-C11 Processor to Isolated Link Coupler Replacement Cable – This 304.8 mm (12 in) cable is used to connect the SLC 500 processor to the Isolated Link Coupler (1747-AIC).
1747-C13
Specialty Module to Isolated Link Coupler Cable - Use a 1747-C13 cable to connect a BASIC or KE module to an Isolated Link Coupler (1747-AIC). Also connects 1747-UIC RS-485
port to AIC or SLC RJ45 port.
Chassis
1746-A4 4-Slot Chassis.
1746-A7 7-Slot Chassis.
1746-A10 10-Slot Chassis.
1746-A13 13-Slot Chassis.
SLC 500 Processor
5/01 This processor offers a basic set of 51 instructions with the choice of 1K or 4K of
memory in a modular hardware configuration. Modular I/O systems that include an
SLC 5/01 processor can be configured with a maximum of three chassis (30 total
slots) and from 4 I/O points to a maximum of 3940 I/O points,1747- L511/L514.
SLC 5/02 This processor offers additional complex instructions, enhanced communications,
faster scan times than the SLC 5/01, and extensive diagnostics that allow it to function
in more complex applications. Modular I/O systems can be configured with a maximum
of 3 chassis (30 total slots) and from 4 I/O points to a maximum of 4096 I/O points,1747- L524.
SLC 5/03 This processor provides 8 K, 16 K, or 32 K of memory. A built-in RS-232 channel gives
you the flexibility to connect to external intelligent devices without the need for
additional modules. Modular I/O systems can be configured with a maximum of 3
chassis (30 total slots) and from 4 I/O points to a maximum of 4096 I/O points,1747- l531/L532/L533.
SLC 5/04 The standard DH-485 port has been replaced with a DH+ port, providing high-speed
SLC 5/04-to-SLC 5/04 communications and direct connection to PLC-5 controllers.
Modular I/O systems can be configured with a maximum of 3 chassis (30 total slots)
and from 4 I/O points to a maximum of 4096 I/O points. The available memory
options are 16 K, 32 K, or 64 K. In addition, there is an SLC 5/04P option, which is
designed specifically for the Plastics Industry and contains ERC2 algorithms for
Plastics Machinery Control,1747-l541/L542/L543.
SLC 5/05 The SLC 5/05 processor provides the same functionality as the SLC 5/04 processor
with standard Ethernet communications rather than DH+ communications. Ethernet
communication occurs at 10 Mbps or 100 Mbps, providing a high performance
network for program upload/download, online editing, and peer-to-peer messaging.
Modular I/O systems can be configured with a maximum of 3 chassis (30 total slots)
and from 4 I/O points to a maximum of 4096 I/O points,1747-l551/L552/L553.
Power Supply
1746-P1
85…132/170…265V ac, 47…63 Hz 2 A 0.46 A 0.2 A @ 24V dc 20 A
1746-P2 85…132/170…265V ac, 47…63 Hz 5 A 0.96 A 0.2 A @ 24V dc 20 A.
1746-P3 19.2…28.8V dc 3.6 A 0.87 A ⎯ 20 A.
1746-P4 85…132/170…250V ac, 47…63 Hz 10 A 2.88 A 1 A @ 24V dc ✶ 45 A.
1746-P5 90…146V dc 5 A 0.96 A 0.2 A @ 24V dc 20 A.
1746-P6 30…60V dc 5 A 0.96 A 0.2 A @ 24V dc 20 A.
1746-P7 10…30V dc, isolated 12V dc input: 2 A.
24V dc input: 3.6 A 12V dc input: 0.46 A 24V dc input: 0.87 A - 20 A.
1763-L16AWA 120/240V AC (10) 120V AC, (2) Analog Voltage,(6) Individually Isolated,Relay.
1763-L16BWA 120/240V AC (6) 24V DC,(4) Fast 24V DC,(2) Analog Voltage,(6) Individually Isolated, Relay, (4) 40 kHZ input.
1763-L16BBB 24V DC (6) 24V DC,(4) Fast 24V DC,(2) Analog Voltage,(2)Individually Isolated,Relay,(2) 24V DC FET,(2) Fast 24V DC FET,(4) 40 kHZ input,(2)40 kHZ output.
1763-L16DWD 12...24V DC (6) 12V DC/24V DC,(4) Fast 12V DC/24V,DC,(2)Analog Voltage.
1763 Expansion I/O Modules
Digital
1762-IA8 8-Point 120V AC Input Module.
1762-IQ8 8-Point Sink/Source 24V DC Input Module.
1762-IQ8OW6 8 Point Sink/Source 24V DC Input/6-Point AC/DC Relay Output Combination Module.
1762-IQ16 16-Point Sink/Source 24V DC Input Module.
1762-L24AWA, -L24AWAR 120/240V AC (14) 120V AC (10) Relay.
1762-L40AWA/L40AWAR 120/240V AC(24)120V AC (16) Relay.
1762-L24BWA/L24BWAR 120/240V AC(10) Standard 24V DC(4)Fast 24V DC (10) Relay (4) 20 kHz input.
1762-L40BWA/L40BWAR 120/240V AC(20) Standard 24V DC(4)Fast 24V DC (16) Relay (4) 20 kHz input.
1762-L24BXB/L24BXBR 24V DC (10)Standard 24V DC(4)Fast 24V DC (5) Relay (4) Standard 24V DC FET(1) Fast 24V DC FET (4) 20 kHz input (1) 20 kHz output.
1762-L40BXB/L40BXBR 24V DC (20)Standard 24V DC (4) Fast 24V DC (8) Relay (7) Standard 24V DC FET(1) Fast 24V DC FET (4) 20 kHz input (1) 20 kHz output.
1764-24AWA 120/240V AC (12) 120V AC (12) Relay, 2 isolated relays per unit.
1764-24BWA 120/240V AC (8) Standard 24V DC (4), Fast 24V DC (12) Relay, 2 isolated relays per unit (4) 20 kHz input.
1764-28BXB 24V DC (8) Standard 24V DC(8), Fast 24V DC(6) Relay, 2 isolated relays per unit (4) Standard 24V DC FET (2) Fast 24V DC FET (8) 20 kHz input (2) 20 kHz output.
1764-24AWA 120/240V AC (12) 120V AC (12) Relay, 2 isolated relays per unit.
1764-24BWA 120/240V AC (8) Standard 24V DC (4), Fast 24V DC (12) Relay, 2 isolated relays per unit (4) 20 kHz input.
1764-28BXB 24V DC (8) Standard 24V DC(8), Fast 24V DC(6) Relay, 2 isolated relays per unit (4) Standard 24V DC FET (2) Fast 24V DC FET (8) 20 kHz input (2) 20 kHz output.
1764-24AWA 120/240V AC (12) 120V AC (12) Relay, 2 isolated relays per unit.
1764-24BWA 120/240V AC (8) Standard 24V DC (4), Fast 24V DC (12) Relay, 2 isolated relays per unit (4) 20 kHz input.
1764-28BXB 24V DC (8) Standard 24V DC(8), Fast 24V DC(6) Relay, 2 isolated relays per unit (4) Standard 24V DC FET (2) Fast 24V DC FET (8) 20 kHz input (2) 20 kHz output.
1764-24AWA 120/240V AC (12) 120V AC (12) Relay, 2 isolated relays per unit.
1764-24BWA 120/240V AC (8) Standard 24V DC (4), Fast 24V DC (12) Relay, 2 isolated relays per unit (4) 20 kHz input.
1764-28BXB 24V DC (8) Standard 24V DC(8), Fast 24V DC(6) Relay, 2 isolated relays per unit (4) Standard 24V DC FET (2) Fast 24V DC FET (8) 20 kHz input (2) 20 kHz output.
D0-05AA (8 AC IN / 6 AC OUT MICRO PLC W/AC P/S)
DL05 CPU, 8 AC in / 6 AC out, 110/220 VAC power supply. 6K words total (2048 words ladder - flash, 4096 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port and additional RS232C communications port. Inputs: 8 AC inputs, 90-120 VAC, 2 isolated commons. Outputs: 6 AC outputs, 17-240 VAC, 0.5A/point max., 2 isolated commons. One option slot available for I/O or communication module.
D0-05AD (8 AC IN / 6 DC OUT MICRO PLC W/AC P/S)
DL05 CPU, 8 AC in / 6 DC out, 110/220 VAC power supply. 6K words total (2048 words ladder - flash, 4096 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port and additional RS232C communications port. Inputs: 8 AC inputs, 90-120 VAC, 2 isolated commons. Outputs: 6 DC outputs, 6-27 VDC current sinking, 1.0A/point max, 1 common. 2 outputs are configurable for independent CW/CCW pulse train output or step and direction pulse output up to 7kHz (0.5A/point). One option slot available for I/O or communication module.
D0-05AR (8 AC IN / 6 RELAY OUT MICRO PLC W/AC P/S)
DL05 CPU, 8 AC in / 6 relay out, 110/220 VAC power supply. 6K words total (2048 words ladder - flash, 4096 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port and additional RS232C communications port. Inputs: 8 AC inputs, 90-120 VAC, 2 isolated commons. Outputs: 6 relay outputs, 6-27 VDC, 6-240 VAC, 2A/point max., 2 isolated commons. One option slot available for I/O or communication module.
D0-05DA (8 DC IN / 6 AC OUT MICRO PLC W/AC P/S)
DL05 CPU, 8 DC in / 6 AC out, 110/220 VAC power supply. 6K words total (2048 words ladder - flash, 4096 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port and additional RS232C communications port. Inputs: 8 DC inputs, 12-24 VDC current sinking/sourcing, 2 isolated commons. First 3 inputs are configurable in one of several high-speed I/O features such as 5kHz counter input, pulse catch input, or interrupt input. Outputs: 6 AC outputs, 17-240 VAC, 0.5A/point max., 2 isolated commons. One option slot available for I/O or communication module.
D0-05DD (8 DC IN / 6 DC OUT MICRO PLC W/AC P/S)
DL05 CPU, 8 DC in / 6 DC out, 110/220 VAC power supply. 6K words total (2048 words ladder - flash, 4096 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port and additional RS232C communications port. Inputs: 8 DC inputs, 12-24 VDC current sinking/sourcing, 2 isolated commons. First 3 inputs are configurable in one of several high-speed I/O features such as 5kHz counter input, pulse catch input, or interrupt input (not available when using pulse output). Outputs: 6 DC outputs, 6-27 VDC current sinking, 1.0A/point max., 1 common. 2 outputs are configurable for independent CW/CCW pulse train output or step and direction pulse output up to 7kHz (0.5A/point) (not available when using high-speed inputs). One option slot available for I/O or communication module.
D0-05DR (8 DC IN / 6 RELAY OUT MICRO PLC W/AC P/S)
DL05 CPU, 8 DC in / 6 Relay out, 110/220 VAC power supply. 6K words total (2048 words ladder - flash, 4096 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port and additional RS232C communications port. Inputs: 8 DC inputs, 12-24 VDC current sinking/sourcing, 2 isolated commons. First 3 inputs are configurable in one of several high-speed I/O features such as 5kHz counter input, pulse catch input, or interrupt input. Outputs: 6 relay outputs, 6-27 VDC, 6-240 VAC, 2A/point max., 2 isolated commons. One option slot available for I/O or communication module.
D0-05DD-D (8 DC IN / 6 DC OUT MICRO PLC DC POWERSUPPLY)
DL05 CPU (requires 12-24 VDC power), 8 DC in / 6 DC out, 12/24 VDC power supply. 6K words total (2048 words ladder - flash, 4096 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port and additional RS232C comm. port. Inputs: 8 DC inputs, 12-24 VDC current sinking/sourcing, 2 isolated commons. First 3 inputs configurable in one of several high-speed I/O features such as 5kHz counter input, pulse catch input, or interrupt input (not available when using pulse output). Outputs: 6 DC outputs, 6-27 VDC current sinking, 1.0A/point max., 1 common. 2 outputs configurable for independent CW/CCW pulse train output or step and direction pulse output up to 7kHz (0.5A/point) (not available when using high-speed inputs). One option slot available for option module.
D0-05DR-D (8 DC IN / 6 RELAY OUT MICRO PLC DC POWERSUPPLY)
DL05 CPU (requires 12-24 VDC power), 8 DC in / 6 Relay out, 12/24 VDC power supply. 6K words total (2048 words ladder - flash, 4096 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port and additional RS232C communications port. Inputs: 8 DC inputs, 12-24 VDC current sinking/sourcing, 2 isolated commons. First 3 inputs are configurable in one of several high-speed I/O features such as 5kHz counter input, pulse catch input, or interrupt input. Outputs: 6 Relay outputs, 6-27 VDC, 6-240 VAC, 2A/point max., 2 isolated commons. One option slot available for I/O or communication module.
D0-06DD1 (DL06 20 DC IN / 16 DC OUT MICRO PLC W/AC P/S)
DL06 CPU, 20 DC in / 16 DC out, 110/220 VAC power supply, with 0.3A 24 VDC auxiliary device power supply. 14.8K words total (7679 words ladder - flash, 7488 words V-memory), RLL/RLLPLUS programming (DirectSOFT32 Version 4.0 or higher), two built-in RS232C communication ports. Secondary communications port supports RS232C/RS422/RS485, DirectNET Master/Slave, MODBUS RTU, Master/Slave, and ASCII In/Out. Inputs: 20 DC inputs, 12-24 VDC current sinking/sourcing, 5 isolated commons (4 inputs per common). First 4 inputs are configurable in one of several high-speed I/O features such as 7KHz counter input, pulse catch input, or interrupt input (not available when using pulse output). Outputs: 16 DC outputs, 12-24 VDC current sinking, 1.0A/point max., 4 commons non-isolated (4 points per common). 2 outputs are configurable for independent CW/CCW pulse train output or step and direction pulse output up to 10kHz (0.5A/point) (not available when using high-speed inputs). Four option slots available for I/O or communication modules.
D0-06DD2 (DL06 20 DC IN / 16 DC OUT MICRO PLC W/AC P/S)
DL06 CPU, 20 DC in / 16 DC out, 110/220 VAC power supply, with 0.3A 24 VDC auxiliary device power supply. 14.8K words total (7679 words ladder - flash, 7488 words V-memory), RLL/RLLPLUS programming (DirectSOFT32 Version 4.0 or higher), two built-in RS232C communication ports. Secondary communications port supports RS232C/RS422/RS485, DirectNET Master/Slave, MODBUS RTU, Master/Slave, and ASCII In/Out. Inputs: 20 DC inputs, 12-24 VDC current sinking/sourcing, 5 isolated commons (4 inputs per common). First 4 inputs are configurable in one of several high-speed I/O features such as 7KHz counter input, pulse catch input, or interrupt input (not available when using pulse output). Outputs: 16 DC outputs, 12-24 VDC current sourcing 1.0A/point max., 4 commons non-isolated (4 points per common). 2 outputs are configurable for independent CW/CCW pulse train output or step and direction pulse output up to 10kHz (0.5A/point) (not available when using high-speed inputs). Four option slots available for I/O or communication modules.
D0-06DR (DL06 20 DC IN / 16 RELAY MICRO PLC W/AC P/S)
DL06 CPU, 20 DC in / 16 Relay out, 110/220 VAC power supply, with 0.3A 24 VDC auxiliary device power supply. 14.8K words total (7679 words ladder - flash, 7488 words V-memory), RLL/RLLPLUS programming (DirectSOFT32 Version 4.0 or higher), two built-in RS232C communication ports. Secondary communications port supports RS232C/RS422/RS485, DirectNET Master/Slave, MODBUS RTU, Master/Slave, and ASCII In/Out. Inputs: 20 DC inputs, 12-24 VDC current sinking/sourcing, 5 isolated commons (4 inputs per common). First 4 inputs are configurable in one of several high-speed I/O features such as 7KHz counter input, pulse catch input, or interrupt input. Outputs: 16 relay outputs, 6-27 VDC, 6-240 VAC, 2A/point max., 4 isolated commons (4 points per common). Four option slots available for I/O or communication modules.
D0-06DA (DL06 20 DC IN / 16 AC OUT MICRO PLC W/AC P/S)
DL06 CPU, 20 DC in / 16 AC out, 110/220 VAC power supply, with 0.3A 24 VDC auxiliary device power supply. 14.8K words total (7679 words ladder - flash, 7488 words V-memory), RLL/RLLPLUS programming (DirectSOFT32 Version 4.0 or higher), two built-in RS232C communication ports. Secondary communications port supports RS232C/RS422/RS485, DirectNET Master/Slave, MODBUS RTU, Master/Slave, and ASCII In/Out. Inputs: 20 DC inputs, 12-24 VDC current sinking/sourcing, 5 isolated commons (4 inputs per common). First 4 inputs are configurable in one of several high-speed I/O features such as 7kHz counter input, pulse catch input, or interrupt input. Outputs: 16 AC outputs, 17-240 VAC, 0.5A/point max., 4 isolated commons (4 points per common). Four option slots available for I/O or communication modules.
D0-06AR: (DL06 20 AC IN / 16 RELAY MICRO PLC W/AC P/S)
DL06 CPU, 20 AC in / 16 Relay out, 110/220 VAC power supply, with 0.3A 24 VDC auxiliary device power supply. 14.8K words total (7679 words ladder - flash, 7488 words V-memory), RLL/RLLPLUS programming (DirectSOFT32 Version 4.0 or higher), two built-in RS232C communication ports. Secondary communications port supports RS232C/RS422/RS485, DirectNET Master/Slave, MODBUS RTU, Master/Slave, and ASCII In/Out. Inputs: 20 AC inputs, 90-120 VAC, 5 isolated commons (4 inputs per common). Outputs: 16 relay outputs, 6-27 VDC, 6-240 VAC, 2A/point max., 4 isolated commons (4 points per common). Four option slots available for I/O or communication modules.
D0-06AA (DL06 20 AC IN / 16 AC OUT MICRO PLC W/AC P/S)
DL06 CPU, 20 AC in / 16 AC out, 110/220 VAC power supply. 14.8K words total (7679 words ladder - flash, 7488 words V-memory), RLL/RLLPLUS programming (DirectSOFT32 Version 4.0 or higher), two built-in RS232C communication ports. Secondary communications port supports RS232C/RS422/RS485, DirectNET Master/Slave, MODBUS RTU, Master/Slave, and ASCII In/Out. Inputs: 20 AC inputs, 90-120 VAC, 5 isolated commons (4 inputs per common). Outputs: 16 AC outputs, 17-240 VAC, 0.5A/point max., 2 isolated commons (8 points per common). Four option slots available for I/O or communication modules.
D0-06DD1-D (DL06 20 DC IN / 16 DC OUT MICRO PLC W/DC P/S)
DL06 CPU (requires 12-24 VDC power), 20 DC in / 16 DC out, 12/24 VDC power supply. 14.8K words total (7679 words ladder - flash, 7488 words V-memory), RLL/RLLPLUS programming (DirectSOFT32 Version 4.0 or higher), two built-in RS232C communication ports. Secondary communications port supports RS232C/RS422/RS485, DirectNET Master/Slave, MODBUS RTU, Master/Slave, and ASCII In/Out. Inputs: 20 DC inputs, 12-24 VDC current sinking/sourcing, 5 isolated commons (4 inputs per common). First 4 inputs are configurable in one of several high-speed I/O features such as 7KHz counter input, pulse catch input, or interrupt input (not available when using pulse output). Outputs: 16 DC outputs, 12-24 VDC current sinking, 1.0A/point max., 4 isolated commons (4 points per common). 2 outputs are configurable for independent CW/CCW pulse train output or step and direction pulse output up to 10kHz (0.5A/point) (not available when using high-speed inputs). Four option slots available for I/O or communication modules.
D0-06DR-D (DL06 20 DC IN / 16 RELAY MICRO PLC W/DC P/S)
DL06 CPU (requires 12-24 VDC power), 20 DC in / 16 Relay out, 12/24 VDC power supply. 14.8K words total (7679 words ladder - flash, 7488 words V-memory), RLL/RLLPLUS programming (DirectSOFT32 Version 4.0 or higher), two built-in RS232C communication ports. Secondary communications port supports RS232C/RS422/RS485, DirectNET Master/Slave, MODBUS RTU, Master/Slave, and ASCII In/Out. Inputs: 20 DC inputs, 12-24 VDC current sinking/sourcing, 5 isolated commons (4 inputs per common). First 4 inputs are configurable in one of several high-speed I/O features such as 7kHz counter input, pulse catch input, or interrupt input. Outputs: 16 Relay outputs, 6-27 VDC, 6-240 VAC, 2A/point max., 4 isolated commons (4 points per common). Four option slots available for I/O or communication modules.
D0-06LCD (DL06 LCD DISPLAY 16 CHAR X 2 ROWS)
DL06 LCD display, 16 characters x 2 rows with backlight, 7 function keys. Installs into any model DL06 PLC; display single bit, 16 bit, or 32 bit I/O or V-memory registers, scan time, PLC mode, system errors, display/change clock calender or user V-memory ranges for setpoints, along with user programmable display and data entry messages. Password protection capable for clock/calendar setup and data value changes in user V-memory registers. LCD programming configured using DirectSOFT programming software version 4.0 or later; D2-HPP LCD programming not supported.
F1-130AA (10 AC INPUT/8 AC OUTPUT 85-265VAC .5A 24VDC)
DL105 CPU, 10 AC in / 8 AC out, 110/220V power supply (94-240 VAC @ 30VA max., 100-240 VDC @ 30W max.). 2.4K words total (2048 words ladder - EEPROM, 384 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port. Inputs: 10 AC inputs, 80-132 VAC or 90-150 VDC, 3 isolated commons. Outputs: 8 AC outputs, 20-140 VAC, 1.7A/pt., 4 isolated commons
F1-130AD (10 AC INPUT/8 DC OUTPUT 85-265VAC .5A 24VDC)
DL105 CPU, 10 AC in / 8 DC out, 110/220V power supply (94-240 VAC @ 30VA max., 100-240 VDC @ 30W max.). 2.4K words total (2048 words ladder - EEPROM, 384 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port. Inputs: 10 AC inputs, 80-132 VAC or 90-150 VDC, 3 isolated commons. Outputs: 8 DC outputs, 5-30 VDC current sinking, 0.5A/pt. max, 3 internally connected commons. 2 outputs are configurable for independent CW/CCW pulse train output or step and direction pulse output up to 7kHz (@ 0.25A/pt. max)
F1-130AR (10 AC INPUT/8 RELAY OUTPUT )
DL105 CPU, 10 AC in / 8 Relay out, 110/220V power supply (94-240 VAC @ 30VA max., 100-240 VDC @ 30W max.). 2.4K words total (2048 words ladder - EEPROM, 384 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port. Inputs: 10 AC inputs, 80-132 VAC or 90-150 VDC, 3 isolated commons. Outputs: 8 relay outputs, 12-30 VDC, 12-250 VAC, 7A/pt. max. or 30-150 VDC, 0.5A resistive/pt. max., 4 isolated commons.
F1-130DA (10 DC INPUT/8 AC OUTPUT 85-265VAC .5A 24VDC)
DL105 CPU, 10 DC in / 8 AC out, 110/220V power supply (94-240 VAC @ 30VA max., 100-240 VDC @ 30W max.). 2.4K words total (2048 words ladder - EEPROM, 384 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port. Inputs: 10 DC inputs, 12-24 VDC current sinking/sourcing, 3 isolated commons. First 4 inputs are configurable in one of several high-speed I/O features such as 5kHz counter input, pulse catch input, or interrupt input. Outputs: 8 AC outputs, 20-140 VAC, 1.7A/pt. max, 4 isolated commons.
F1-130DD (10 DC INPUT/8 DC OUTPUT 85-265VAC .5A 24VDC)
DL105 CPU, 10 DC in / 8 DC out, 110/220V power supply (94-240 VAC @ 30VA max., 100-240 VDC @ 30W max.). 2.4K words total (2048 words ladder - EEPROM, 384 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port. Inputs: 10 DC inputs, 12-24 VDC current sinking/sourcing, 3 isolated commons. First 4 inputs are configurable in one of several high-speed I/O features such as 5kHz counter input, pulse catch input, or interrupt input (not available when using pulse output). Outputs: 8 DC outputs, 5-30 VDC current sinking, 0.5A/pt. max, 3 internally connected commons. 2 outputs are configurable for independent CW/CCW pulse train output or step and direction pulse output up to 7kHz (@ 0.25A/pt. max) (not available when using high-speed inputs)
F1-130DR (10 DC INPUT/8 RELAY OUTPUT 85-265VAC .5A 24VDC)
DL105 CPU, 10 DC in / 8 relay out, 110/220V power supply (94-240 VAC @ 30VA max., 100-240 VDC @ 30W max.). 2.4K words total (2048 words ladder - EEPROM, 384 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port. Inputs: 10 DC inputs, 12-24 VDC current sinking/sourcing, 3 isolated commons. First 4 inputs are configurable in one of several high-speed I/O features such as 5kHz counter input, pulse catch input, or interrupt input. Outputs: 8 relay outputs, 12-30 VDC, 12-250 VAC, 7A/pt. max. or 30-150 VDC, 0.5A resistive/pt. max., 4 isolated commons.
F1-130DD-D (10 DC INPUT/8 DC OUTPUT 10-30VDC P/S)
DL105 CPU (requires 12-24 VDC power), 10 DC in / 8 DC out, 12/24 VDC power supply. 2.4K words total (2048 words ladder - EEPROM, 384 words V-memory) RLL/RLLPLUS programming, built-in RS232C programming port. Inputs: 10 DC inputs, 12-24 VDC current sinking/sourcing, 3 isolated commons. First 4 inputs are configurable in one of several high-speed I/O features such as 5kHz counter input, pulse catch input, or interrupt input (not available when using pulse output). Outputs: 8 DC outputs, 5-30 VDC current sinking, 0.5A/pt. max, 3 internally connected commons. 2 outputs are configurable for independent CW/CCW pulse train output or step and direction pulse output up to 7kHz (@ 0.25A/pt. max) (not available when using high-speed inputs)
F1-130DR-D (10 DC INPUT/8 RELAY OUTPUT 10-30VDC P/S)
DL105 CPU (requires 12-24 VDC power), 10 DC in / 8 relay out, 12/24 VDC power supply. 2.4K words total (2048 words ladder - EEPROM, 384 words V-memory) RLL/RLLPLUS programming, built-in RS232C programming port. Inputs: 10 DC inputs, 12-24 VDC current sinking/sourcing, 3 isolated commons. First 4 inputs are configurable in one of several high-speed I/O features such as 5kHz counter input, pulse catch input, or interrupt input. Outputs: 8 relay outputs, 12-30 VDC, 12-250 VAC, 7A/pt. max. or 30-150 VDC, 0.5A resistive/pt. max., 4 isolated commons.
D2-250-1 (CPU 14.8K WORDS W/4-LOOPS & FLOATING PT MATH)
D2-250-1 CPU, (direct replacement for previous D2-250) 14.8K words total (7680 words ladder - flash memory, 7168 words V-memory), RLL/RLLPLUS programming, two built-in RS232C ports. Bottom port also supports Remote I/O Master, RS422, DirectNET Master/Slave, Modbus RTU Master/Slave. Advanced instruction set includes up to 4 PID loops. Also supports new DL205 -1 local base expansion, up to two additional bases. Requires DirectSOFT Release 2.1 or later for programming, and 4.0 or later for local expansion support. Battery not included.
D2-260 (CPU 30.4K WORDS W/16-LOOPS FLOATING PT MATH)
D2-260 CPU, 30.4K words total (15.8K words ladder - flash memory, 14.6K words V-memory), RLL/RLLPLUS programming, real time clock/calendar, two built-in RS232C ports. Bottom port also supports Remote I/O Master, DirectNET Master/Slave RS422, Modbus RTU Master/Slave RS485/RS422, and ASCII In/Out. Advanced instruction set includes up to 16 PID loops, ASCII In/Out instructions, and Modbus RTU instructions. Also supports new DL205 -1 local base expansion, up to four additional bases. Requires DirectSOFT Release 4.0 or later for programming. Battery not included.
F3-OMUX-1: (BRIDGE CPU TWO NON-ISOLATED 232/422/485 PORTS)
FACTS Bridge CPU, two non-isolated RS232C/RS422/RS485 ports, interfaces DL305 I/O modules to a host computer with an OPTOMUX (tm) compatible driver, custom cable required.
F3-OMUX-2: (BRIDGE CPU TWO ISOLATED 422/485 PORTS)
FACTS Bridge CPU, two isolated RS422/RS485 ports, interfaces DL305 I/O modules to a host computer with an OPTOMUX (tm) compatible driver, custom cable required.
F3-PMUX-1: (BRIDGE CPU WITH 50-PIN HIGH SPEED PARALLEL BUS)
FACTS Bridge CPU, Interfaces DL305 I/O modules to a host computer with a Pamux compatible driver, via a 50-pin high-speed parallel bus, custom cable required. Note: replaces F3-PMUX. F3-PMUX-1 has 26Mhz processor.
D3-330: (CPU RLL 3.7K WDS)
D3-330 CPU, 3.7K words RAM, RLL programming (DC-232-DCU or D2-422-DCU required if using Windows-based programming.).
D3-350: (CPU 14.8K WDS TOT MEM W LOOPS & FLOAT PT MTH)
D3-350 CPU, 14.8K words total (7680 words ladder - EEPROM, 7168 words V-memory), RLL/RLLPLUS programming, two built-in RS232C ports. Bottom port also supports RS422, DirectNET Master/Slave, Modbus RTU Master/Slave. Advanced instruction set includes up to 4 PID loops.
D4-430: (CPU AC P/S 6.5K MEMORY 232 & 232/422 PORT)
D4-430 CPU, 6.5K words total memory, (3.5K ladder - EEPROM, 3.0K V-memory), RLL/RLLPLUS programming, built-in RS232C programming port and aux RS232C/422 port, internal 110/220 VAC power supply (memory cartridge cannot be used to expand memory).
D4-440: (CPU AC P/S 22.5K (CART REQ) 232 & 232/422 PORT)
D4-440 CPU, 22.5K words total memory, (15.5K ladder - RAM, UVPROM, or EEPROM , 7.0K V-memory) RLL/RLLPLUS programming, built-in RS232C programming port and auxiliary RS232C/RS422 port, internal 110/220 VAC power supply (requires memory cartridge).
D4-440DC-1: (CPU 24VDC P/S 22.5K CARTREQ 232 & 232/422 PORT)
D4-440DC-1 CPU, 22.5K words total memory, (15.5K ladder - RAM, UVPROM, or EEPROM , 7.0K V-memory) RLL/RLLPLUS programming, built-in RS232C programming port and auxiliary RS232C/RS422 port, internal 24 VDC power supply (requires memory cartridge).
D4-440DC-2: (CPU125VDC P/S 22.5K CARTREQ 232 & 232/422 PORT)
D4-440DC-2 CPU, 22.5K words total memory, (15.5K ladder - RAM, UVPROM, or EEPROM , 7.0K V-memory) RLL/RLLPLUS programming, built-in RS232C programming port and auxiliary RS232C/RS422 port, internal 125 VDC power supply (requires memory cartridge).
D4-450: (CPU AC P/S 31.5K MEMORY 232 & 232/422 PORT)
D4-450 CPU, 30.8K words total memory. 7.5K flash ladder memory on board or use optional memory cartridge for up to 15.5K ladder (RAM, UVPROM, or EEPROM cartridges available). RLL/RLLPLUS programming including support for up to 16 PID loops and floating point math. Built-in communication ports including an RS232C programming port and auxiliary RS232C/RS422 ports. Internal 110/220 VAC power supply (memory cartridge is optional). NOTE: If the D4-450 is replacing a CPU in an existing system, and the system has specialty modules with an F4 part number, (CoPros, SDN, etc.) please contact our Technical Services group before ordering. These modules may require an upgrade to operate with the D4-450. (Does not apply to analog modules).
D4-450DC-1: (DL450 CPU W 24V DC POWER SUPPLY)
D4-450DC-1 CPU, 30.8K words total memory. 7.5K flash ladder memory on board or use optional memory cartridge for up to 15.5K ladder (RAM, UVPROM, or EEPROM cartcartridges available). RLL/RLLPLUS programming, with support for up to 16 PID loops and floating point math. Built-in comm ports including an RS232C programming port and auxiliary RS232C/RS422 ports, internal 24 VDC power supply (memory cartridge is optional).
D4-450DC-2: (DL450 CPU W 125V DC POWER SUPPLY)
D4-450DC-2 CPU, 30.8K words total memory. 7.5K flash ladder memory on board or use optional memory cartridge for up to 15.5K ladder (RAM, UVPROM, or EEPROM cartcartridges available). RLL/RLLPLUS programming, with support for up to 16 PID loops and floating point math. Built-in comm ports including an RS232C programming port and auxiliary RS232C/RS422 ports, internal 125 VDC power supply (memory cartridge is optional).
PC-DSDATA (DIRECTSOFT32 DSDATA SERVER S/W & MANUAL)
Not recommended for new development. Use PC-KEPPLC OPC servers as replacement. DirectSOFT32 Windows DDE/OPC Server software for DL05/DL06/DL105/205/305/405,Windows 98/2000/NT or XP
PC-DSOFT5 (DIRECTSOFT5 PROGRAMMING SW LADDER LOGIC EDITOR FOR DL PLC'S)
DirectSOFT (r) 5, Version 5.0 or higher, Windows PC programming and documentation software, programs DL05/06/105/205/305/405, includes software on CD-ROM and manual. Windows 2000 or Windows XP (Pro or Home) or Windows Vista (Home, Basic, Premium)
EA-MG-PGMSW (C-MORE MICRO-GRAPHIC PANEL PROGRAMMING SOFTWARE)
C-more Micro-Graphic panel Windows-based configuration software. Requires Windows 2000 (Service Pack 4) or XP Home or Professional (Service Pack 2) or Vista.
EZ-TOUCHEDIT (PROGRAMMING SOFTWARE EZ TOUCH)
EZTouch Operator Panels Windows-based configuration software. Requires Windows 95/98/NT, 2000 or XP Home/Professional. Includes manual and CD-ROM. Cables sold separately.
D2-DSCBL (PC PROGRAMMING CABLE FOR DL05/06 DL105 205 350 450 & CLICK )
12 ft. (3.66m) RS232 shielded PC programming cable for DL05, DL06, DL105, DL205, D3-350, D4-450 and CLICK CPUs. 9-pin D-shell female connector to an RJ12 6P6C connector.
D2-DSCBL-1 (D2-250 PC PROGRAMMING CABLE FOR BOTTOM PORT)
12 ft. (3.66m) RS232 shielded PC programming cable for DL06, D2-250(-1), D2-260 CPUs and D0-DCM. 9-pin D-shell female connector to a 15-pin male HD15 connector.
D3-DSCBL-1 (PC PROGRAMMING CABLE FOR D3-340 CPU)
12 ft. (3.66m) RS232 shielded PC programming cable for the D3-340 CPU. 9-pin D-shell female connector to an RJ11 connector.
D3-DSCBL-2 (PC PGMING CABLE 330/330P/ 350 DL405 BTM PORT)
12 ft. (3.66m) RS232 shielded PC programming cable for the D3-330 & D3-330P CPUs. An RS232 Data Communications Unit is also required to use this cable. 9-pin D-shell female connector to a 25-pin D-shell male connector. Can also be used to connect to the bottom port of a DL405 or D3-350 CPU, or to DL205/DL305/DL405 DCM modules.
D4-DSCBL (DL 405 PROGRAMMING CABLE 12FT)
12 ft. (3.66m) RS232 shielded PC programming cable for the 15-pin port on the DL405 CPUs. 9-pin D-shell female connector to a 15-pin D-shell male connector. For programming over the DL405 25-pin port, use D3-DSCBL-2.
DA-DSCBL (DIRECTSOFT PROGRAMMING CABLE KIT)
Single kit containing 1 each of: D2-DSCBL, D3-DSCBL-1, D3-DSCBL-2, D4-DSCBL.
OP-CCBL (CABLE TO CONNECT TO ANY OP400 SERIES)
Configuration cable to connect your personal computer to any OP400 series Optimate unit for setup and programming. 2m (6.56ft) RS232C cable, RJ12 modular plug to 9-pin D-shell female connector. OP-PS400 power supply also required to configure OP400 panels
OP-ACBL-1 (OP PGM CBL & SLC 5/03 & /04 15 IN MALE-9 PIN FEM)
Configuration cable to connect your personal computer to any OP600 or OP1000 series Optimate unit for setup and programming. Also used for connecting any OP600 or OP1000 series OptiMate unit to an Allen-Bradley SLC5/03 & SLC5/04 CPUs with a 9-pin connector. 2m (6.56ft) RS232C cable, 15-pin D-shell male connector to 9-pin D-shell female connector.
DP-PGMCBL (DIRECT TOUCH PROGRAMMING CABLE)
Configuration cable to connect your personal computer to any DirectTouch panel for downloading/uploading. 2m (6.56 ft.) RS232C cable, 9-pin D-shell male connector to 9-pin D-shell female connector.
OP-406: (OPTIMATE INDICATOR/ PUSHBUTTON PANEL)
OptiMate Indicator/Pushbutton panel. Offers 6 lamps and 4 pushbuttons with LED indicators. Supports DL05, DL06, DL105, DL205, DL305, DL405 and Allen-Bradley SLC5/03 & SLC5/04, and Micrologix CPUs. Cables, connectors, and Configuration software sold separately. OP-PS400 is required for panel configuration and operation. Do not power from PLC communication port.
OP-413: (SETPOINT/DISPLAY PANEL )
OptiMate Setpoint/Display panel. Offers a 4-digit numeric LED display and setpoint adjustment pushbuttons; supports 6 field points. Supports DL05, DL06, DL105, DL205, DL305, DL405 and A-B SLC5/03 & SLC5/04, and Micrologix CPUs. Cables, connectors, and Configuration software sold separately. OP-PS400 required for configuration and operation. Do not power from PLC communication port.
OP-414: (SETPOINT/DISPLAY PANEL W 8 DIGIT LED DISPLAY)
OptiMate Setpoint/Display panel. Offers an 8-digit numeric LED display and setpoint adjustment pushbuttons; supports 6 field points. Supports DL05, DL06, DL105, DL205, DL305, DL405 and Allen-Bradley SLC5/03 & SLC5/04, and Micrologix CPUs. Cables, connectors, and Configuration software sold separately. OP-PS400 required for configuration and operation. Do not power from PLC communication port.
OP-420: (OPERATOR PANEL W 2 LINE X 20 CHARACTER LCD)
OptiMate Operator panel. Offers a 2 line x 20 character LCD display and four function keys with LED indicators. Supports DL05, DL06, DL105, DL205, DL305, DL405 and Allen-Bradley SLC5/03 & SLC5/04, and Micrologix CPUs. Cables, connectors, and Configuration software sold separately. OP-PS400 required for configuration and operation. Do not power from PLC communication port.
.
OP-440: (DISPLAY PANEL 4 LINE X 20 CHARACTER LCD)
OptiMate Display panel. Offers a 4 line x 20 character LCD display. Supports DL05, DL06, DL105, DL205, DL305, DL405 and Allen-Bradley SLC5/03 & SLC5/04, and Micrologix CPUs. Cables, connectors, and Configuration software sold separately. OP-PS400 required for configuration and operation. Do not power from PLC communication port.
OP-ACBL-1 (OP PGM CBL & SLC 5/03 & /04 15 IN MALE-9 PIN FEM)
Configuration cable to connect your personal computer to any OP600 or OP1000 series Optimate unit for setup and programming. Also used for connecting any OP600 or OP1000 series OptiMate unit to an Allen-Bradley SLC5/03 & SLC5/04 CPUs with a 9-pin connector. 2m (6.56ft) RS232C cable, 15-pin D-shell male connector to 9-pin D-shell female connector.
OP-609: (OPTIMATE ANNUNCIATOR/ PUSHBUTTON PANEL)
OptiMate Annunciator/Pushbutton panel. Offers 6 lamps and 9 pushbuttons. Supports DL05, DL06, DL105, DL205, DL305, DL405 and Allen-Bradley SLC5/03 & SLC5/04, and Micrologix CPUs.
OP-613: (OPTIMATE SETPOINT/ OPERATOR PANEL)
OptiMate Setpoint/Operator panel. Offers 2 red annunciator lamps, 4 pushbuttons, and a 4-digit numeric display. Supports DL05, DL06, DL105, DL205, DL305, DL405 and Allen-Bradley SLC5/03 & SLC5/04 and Micrologix CPUs.
OP-620: (OPTIMATE OPERATOR PANEL )
OptiMate Operator Panel. Has 5 user-defined pushbuttons, arrow adjust, menu and data setpoint and display. The LCD display is 2 line x 20 characters. Works with DL05, DL06, DL105, DL205, DL305, DL405 and Allen-Bradley SLC5/03 & SLC5/04 and Micrologix CPUs.
OP-640: (OPERATOR PANEL 4 LN X 20 CHAR & 5 PUSHBUTTONS)
OptiMate Operator panel. Offers a 4 line x 20 character LCD display, 3 LED lamps, and 5 pushbuttons with LED indicators. Supports DL05, DL06, DL105, DL205, DL305, DL405 and Allen-Bradley SLC5/03 & SLC5/04, and Micrologix CPUs.
OP-1124: (ANNUNCIATOR PANEL W/24 LAMPS RED LEDS)
OptiMate Annunciator Panel with 24 red panel lamps. Works with DL05, DL06, DL105, DL205, DL305, DL405, A-B SLC 5/03, SLC 5/04, Micrologix, GE Fanuc Series 90 Micro, GE 90/30 Series (SNP) and Modbus (RTU).
OP-1224: (PUSHBUTTON PANEL W/24 BUTTONS)
OptiMate Pushbutton unit with 24 buttons. Works with DL05, DL06, DL105, DL205, DL305, DL405, A-B SLC 5/03, SLC 5/04, Micrologix, GE Fanuc Series 90 Micro, GE 90/30 Series (SNP) and Modbus (RTU).
OP-1312: (DISPLAY/SETPOINT PANEL )
OptiMate Display/Setpoint unit. Works with DL05, DL06, DL105, DL205, DL305, DL405, A-B SLC 5/03, SLC 5/04, Micrologix, GE Fanuc Series 90 Micro, GE Fanuc 90/30 Series (SNP) and Modbus (RTU).
OP-1510: (OPERATOR PANEL 2 X 20 CHAR DISPLAY)
OptiMate Operator Panel. Has 2 function keys, 3 menu select keys, numeric keypad and 2 line x 20 character LCD display. Works with DL05, DL06, DL105, DL205, DL305, DL405, A-B SLC 5/03, SLC 5/04, Micrologix, GE Fanuc Series 90 Micro, GE Fanuc 90/30 Series (SNP) and Modbus (RTU).
OP-1312: (DISPLAY/SETPOINT PANEL )
OptiMate Display/Setpoint unit. Works with DL05, DL06, DL105, DL205, DL305, DL405, A-B SLC 5/03, SLC 5/04, Micrologix, GE Fanuc Series 90 Micro, GE Fanuc 90/30 Series (SNP) and Modbus (RTU).
DV-1000: (TMR/CTR ACCESS FOR DL05/ 06/ 105/ 205/ 405/ D3-350)
DirectVIEW 1000 Timer/Counter access unit for DL05, DL06, DL105, DL205, DL350, and DL405 CPUs. Can be used to change preset values, display discrete bit ranges, display user defined messages, and display system error messages.
LOGO! 24
6ED1 052-1CC00-0BA6 tensión de alimentación 24 V DC; 8 entradas digitales 24 V DC, de ellas 4 utilizables analógicamente (0 ... 10 V); 4 salidas digitales 24 V DC, 0,3 A; 200 bloques de función interconectables, ampliable modularmente.6ED10521CC000BA6
LOGO! 12/24RC
6ED1 052-1MD00-0BA6 tensión de alimentación 12/24 V DC; 8 entradas digitales 12/24 V DC, de ellas 4 utilizables analógicamente (0 ... 10 V); 4 salidas de relé 10 A; programador horario integrado; 200 bloques de función interconectables; ampliable modularmente.6ED10521MD000BA6
LOGO! 24RC
6ED1 052-1HB00-0BA6 tensión de alimentación 24 V AC/DC; 8 entradas digitales 24 V AC/DC; 4 salidas de relé 10 A; programador horario integrado; 200 bloques de función interconectables; ampliable modularmente.6ED10521HB000BA6
LOGO! 230RC
6ED1 052-1FB00-0BA6 tensión de alimentación 115/230 AC/DC; 8 entradas digitales 115/230 V AC/DC; 4 salidas de relé 10 A;
programador horario integrado; 200 bloques de función interconectables; ampliable modularmente.6ED10521FB000BA6
-Visualizador de textos de 4 líneas-
6ED1 055-4MH00-0BA0 Visualizador de textos de 4 líneas, conectable a todas las variantes LOGO! 0BA6 Basic y Pure, incluye cable de conexión.6ED10554MH000BA0
-LOGO! Memory Card -
6ED1 056-1DA00-0BA0 Modulo de programa para copiar con protección de know-how.6ED10561DA000BA0
-LOGO! Battery Card -
6ED1 056-6XA00-0BA0 Modulo de batería para respaldar el reloj de tiempo real integrado (excepto LOGO! 24).6ED10566XA000BA0
-LOGO! Memory/Battery Card -
6ED1 056-7DA00-0BA0 Modulo combinado de programa y batería, con protección del know-how y respaldo del reloj de
tiempo real integrado (excepto LOGO! 24).6ED10567DA000BA0
-LOGO! Soft Comfort V6.0 -
6ED1 058-0BA02-0YA0 para programar en el PC en KOP/FUP; ejecutable a partir de Windows 98, Linux, MAC OSX; en CD-ROM.6ED10580BA020YA0
-LOGO! Cable PC -
6ED1 057-1AA00-0BA0 para transferir el programa entre el LOGO! y la PC.6ED10571AA000BA0
-LOGO! Cable USB-PC -
6ED1 057-1AA01-0BA0 Para transferir programas entre LOGO! y PC, drivers incluidos en el CD-ROM.6ED10571AA010BA0
-LOGO! Modem Cable -
6ED1 057-1CA00-0BA0 Cable adaptador para comunicación vía modem analógico.6ED10571CA000BA0
-SIPLUS LOGO! 24 -
6AG1 052-1CC00-2BA5 (Rango de temperatura ampliado y presencia de atmosfera agresiva)
tensión de alimentación 24 V DC; 8 entradas digitales 24 V DC, de ellas 2 utilizables analógicamente (0 ... 10 V); 4 salidas digitales 24 V DC, 0,3 A; 130 bloques de función interconectables, ampliable modularmente.
-SIPLUS LOGO! 12/24RC -
6AG1 052-1MD00-2BA5 (Rango de temperatura ampliado y presencia de atmosfera agresiva) tensión de alimentación 12/24 V DC; 8 entradas digitales 12/24 V DC, de ellas 2 utilizables analógicamente (0 ... 10 V); 4 salidas de relé 10 A; programador horario integrado; 130 bloques de función interconectables; ampliable modularmente.
-SIPLUS LOGO! 24RC -
6AG1 052-1HB00-2BA5 (Rango de temperatura ampliado y presencia de atmosfera agresiva) tensión de alimentación 24 V
AC/DC; 8 entradas digitales 24 V AC/DC; 4 salidas de relé 10 A; programador horario integrado; 130 bloques de función Interconectables; ampliable modularmente.
-SIPLUS LOGO! 230RC -
6AG1 052-1FB00-2BA5 (Rango de temperatura ampliado y presencia de atmosfera agresiva) tensión de alimentación 115/230 AC/DC; 8 entradas digitales 115/230 V AC/DC; 4 salidas de relé 10 A; programador horario integrado; 130 bloques de función interconectables; ampliable modularmente.
-Modulo logico LOGO! 24o -
6ED1 052-2CC00-0BA6 tensión de alimentación 24 V DC, 8 entradas digitales 24 V DC, de ellas 4 usables análoga. (0 ... 0 V),4 salidas digitales 24 V DC, 0,3 A; sin visualizador ni teclado, 200 bloques de función interconectables, ampliable modularmente.
-Modulo logico LOGO! 12/24RCo -
6ED1 052-2MD00-0BA6 tensión de alimentación 12/24 V DC, 8 entradas digitales 12/24 V DC, de ellas 4 usables análoga (0 ... 10 V), 4 salidas de relé 10 A, programador horario integrado, sin visualizador ni teclado, 200 bloques de función interconectables,ampliable modularmente.
-SIPLUS LOGO! 24RCo-
6AG1 052-2HB00-2BA5 Rango de temperatura -25 ... +70 °C. 6AG1 052-2HB00-2BY5 Rango de temperatura -40 ... +70 °C.
(Rango de temperatura ampliado y presencia de atmosfera agresiva) tensión de alimentación 24 V AC/DC, 8 entradas digitales 24 V AC/DC, 4 salidas de relé 10 A, programador horario integrado, sin visualizador ni teclado, 130 bloques de función interconectables, ampliable modularmente.
-Modulo logico LOGO! 230RCo-
6ED1 052-2FB00-0BA6 tensión de alimentación 115/230 V AC/DC, 8 entradas digitales 115/230 V AC/DC, 4 salidas de relé 10 A, programador horario integrado, sin visualizador ni teclado, 200 bloques de función interconectables, ampliable modularmente.
-LOGO! DM8 24 -
6ED1 055-1CB00-0BA0 tensión de alimentación 24 V DC, 4 entradas digitales 24 V DC, 4 salidas digitales 24 V DC, 0,3 A
LOGO! DM16 24.
-LOGO! DM16 24-
6ED1 055-1CB10-0BA0 tensión de alimentación 24 V DC, 8 entradas digitales 24 V DC, 8 salidas digitales 24 V DC, 0,3 A.
-LOGO! DM8 12/24R -
6ED1 055-1MB00-0BA1 tensión de alimentación 12/24 V DC, 4 entradas digitales 12/24 V DC, 4 salidas de relé 5 A.
-LOGO! DM8 24R-
6ED1 055-1HB00-0BA0 tensión de alimentación 12/24 V DC, 4 entradas digitales 12/24 V DC, 4 salidas de relé 5 A.
-LOGO! DM16 24R -
6ED1 055-1NB10-0BA0 tensión de alimentación 24 V AC/DC, 4 entradas digitales 24 V AC/DC, 4 salidas de relé 5 A.
-LOGO! DM8 230R-
6ED1 055-1FB00-0BA1 tensión de alimentación 115/230 V AC/DC, 4 entradas digitales 115/230 V AC/DC, 4 salidas de relé 5 A.
-LOGO! DM16 230R -
6ED1 055-1FB10-0BA0 tensión de alimentación 115/230 V AC/DC, 8 entradas digitales 115/230 V AC/DC, 8 salidas de relé 5 A.
-LOGO! AM2-
6ED1 055-1MA00-0BA0 tensión de alimentación 12/24 V DC, 2 entradas analógicas de 0 a 10 V o de 0 a 20 mA, resolución
de 10 bits.
-LOGO! AM2 PT 100-
6ED1 055-1MD00-0BA0 tensión de alimentación 12/24 V DC, 2 entradas analógicas Pt100, rango de temperatura de -50 °C a
200 °C.
-LOGO! AM2 AQ-
6ED1 055-1MM00-0BA0 tensión de alimentación 24 V DC, 2 salidas analógicas de 0 a 10 V.
-LOGO! DM8 24 -
Rango de temperatura ampliado y presencia de atmosfera agresiva) tensión de alimentación 24 V DC, 4 entradas digitales 24 V DC, 4 salidas digitales 24 V DC, 0,3 A 6AG1 055-1CB00-2XB0 Rango de temperatura -25 ... +70 °C.
6AG1 055-1CB00-2BY0 Rango de temperatura -40 ... +70 °C.
-LOGO! DM8 12/24 -
6AG1 055-1PB00-2XB0 (Rango de temperatura ampliado y presencia de atmosfera agresiva) tensión de alimentación 12/24 V
DC, 4 entradas digitales 12/24 V DC, 4 salidas digitales 24 V DC, 0,3 A
SIPLUS LOGO! DM8 24R (Rango de temperatura ampliado y presencia de atmosfera agresiva) tensión de alimentación 24 V
AC/DC, 4 entradas digitales 24 V AC/DC, 4 salidas de relé 5 A. 6AG1 055-1HB00-2XB0 Rango de temperatura -25 ... +70 °C
6AG1 055-1HB00-2BY0 Rango de temperatura -40 ... +70 °C.
-LOGO! Modulo de comunicación-
6BK1 700-0BA00-0AA1 CM EIB KNX para conectar al bus EIB, tensión de alimentación 24 VDC
-LOGO! Modulo de conexión-
3RK1 400-0CE10-0AA2 Modulo de conexión a AS-Interface para LOGO!.3RK14000CE100AA2
-LOGO!Power 12 V 1,9 A-
6EP1 321-1SH02 tensión de entrada 100-240 V AC tensión de salida12 V DC, 1,9 A.6EP13211SH02
-LOGO!Power 12 V 4,5 A-
6EP1 322-1SH02 tensión de entrada 100-240 V AC tensión de salida12 V DC, 4,5 A.6EP13221SH02
-LOGO!Power 24 V 1,3 A-
6EP1 331-1SH02 tensión de 24 V 1,3 A entrada 100-240 V AC tensión de salida 24 V DC, 1,3 A.6EP13311SH02
-LOGO!Power 24 V 2,5 A-
6EP1 332-1SH42 tensión de entrada 100-240 V AC tensión de salida 24 V DC, 2,5 A.6EP13321SH42
-LOGO!Power 24 V 4 A-
6EP1 332-1SH51 tensión de entrada 100-240 V AC tensión de salida 24 V DC, 4 A.6EP13321SH51
